CRANKSHAFT/PISTON/ROTARY VALVE (
G4TRA 1971 USA CANADA
Crankshaft/piston/rotary valve ( diagram G4TRA 1971 USA CANADA
CRANKSHAFT/PISTON/ROTARY VALVE ( G4TRA 1971 USA CANADA
×
prices are in EUR
ref
part #
description
quantity
1
13001037
ref: 1
PISTON,STD
€ 30.50
1
13029036
ref: 1
PISTON,0.020' O.S
€ 56.00
1
13027036
ref: 1
PISTON,0.040' O.S
€ 32.50
2
13008023
ref: 2
RING SET,STD
€ 47.00
2
13025026
ref: 2
RING SET,0.020 O/S
€ 128.00
2
13024030
ref: 2
RING SET,0.040 O/S
€ 51.50
3
13002007
ref: 3
PIN
€ 13.00
4
92036007
ref: 4
CIRCLIP-PISTON PIN
€ 2.50
5
13033028
ref: 5
BEARING-NEEDLE,72KTV0
€ 13.50
6
13036034
ref: 6
CRANK&CONROD ASSY
€ 317.50
6
13036034
ref: 6
CRANK&CONROD ASSY
€ 317.50
7
13037018
ref: 7
USE FOR 13036-011/02
CRANKSHAFT,L.H
€ 44.50
7
13037044
ref: 7
USE FOR 13036-031/03
CRANKSHAFT,L.H
€ 317.50
8
13044008
ref: 8
USE FOR 13036-011/02
CONNECTING ROD SET
€ 96.00
8
13044019
ref: 8
USE FOR 13036-081/03
CONNECTING ROD SET
€ 317.50
9
92025005
ref: 9
SHIM,20X34.5X1.0
€ 4.50
9
92025047
ref: 9
SHIM,T=1.0
€ 7.50
10
13035008
ref: 10
USE FOR 13036-011/02
CRANK PIN
€ 10.00
10
13035025
ref: 10
USE FOR 13036-031/03
PIN-CRANK
€ 19.00
11
13034018
ref: 11
USE FOR 13035-008
BRG-KT202612PC
€ 6.00
11
13034025
ref: 11
USE WITH 13035-025
BRG-PK192611.8X
€ 27.50
12
13038012
ref: 12
USE FOR 13036-011/02
CRANKSHAFT,R.H
€ 54.00
12
13038040
ref: 12
USE FOR 13036-031/03
CRANKSHAFT,R.H
€ 317.50
13
610A0410
ref: 13
ROLLER,4X10
€ 2.50
14
92038003
ref: 14
WOODRUFF KEY-PRY PINI
€ 1.50
15
92027022
ref: 15
COLLAR-CRANKSHAFT
€ 7.00
16
670B2016
ref: 16
O RING,16MM
€ 1.00
17
12001004
ref: 17
VALVE-ROTARY DISC
€ 64.50
18
92024003
ref: 18
WASHER,CLAW,12.5X25X0
€ 2.50
19
92015006
ref: 19
NUT,12MM
€ 3.50
20
510A3200
ref: 20
KEY-WOODRUFF
€ 1.50
21
461F1000
ref: 21
WASHER-SPRING,10MM
€ 0.50
22
314B1000
ref: 22
NUT,10MM
€ 0.50
