SWING ARM/SHOCK ABSORBERS ('69-'

ref

part #

description

quantity

1

33001023
ref: 1

SWING ARM

€ 253.00

2

33032008
ref: 2

SHAFT,SWING ARM PIVOT

€ 10.00

2

33032009
ref: 2

SHAFT-SWING ARM PIVOT

€ 12.50

3

92092006
ref: 3

BUSHING-RUBBER,SWING

€ 11.50

4

33040008
ref: 4

ADJUSTER-CHAIN

€ 7.00

5

92076008
ref: 5
L=70 M/M

RUBBER-REAR FOOTREST

€ 5.50

5

92076016
ref: 5
L=90 M/M

RUBBER-REAR FOOTREST

€ 2.50

6

34028005
ref: 6
OLD JIS THREAD

BAR-REAR FOOTREST

€ 7.00

6

34028006
ref: 6
I.S.O. THREAD

BAR-REAR FOOTREST

€ 4.00

6

34029004
ref: 6
OLD JIS THREAD

FOOTREST,REAR

€ 20.00

6

34029003
ref: 6
I.S.O. THREAD

FOOTREST BAR,REAR

€ 10.50

8

92020005
ref: 8
OLD JIS THREAD

NUT-SHOCK ABSBR FIT

€ 3.00

8

92020014
ref: 8
I.S.O. THREAD

NUT,CAP,12MM

€ 6.50

9

43007007
ref: 9

TORQUE LINK,REAR BRK

€ 6.50

10

43009001
ref: 10

PIN-REAR TORQUE LINK

€ 4.50

11

92003003
ref: 11

BOLT-HEX HEAD,10X32

€ 4.00

12

45014038
ref: 12

SHOCK ABSORBER,REAR

€ 1,041.00

13

311B0600
ref: 13

NUT,6MM

€ 0.50

14

410B0600
ref: 14

WASHER-PLAIN-SMALL,6M

€ 0.50

15

461F0600
ref: 15

WASHER-SPRING,6MM

€ 0.50

16

314B1000
ref: 16

NUT,10MM

€ 0.50

17

410B1000
ref: 17

WASHER-PLAIN-SMALL,10

€ 0.50

18

461F1000
ref: 18

WASHER-SPRING,10MM

€ 0.50

19

411B1200
ref: 19

WASHER-PLAIN,12MM

€ 0.50

20

461F1200
ref: 20

WASHER-SPRING,12MM

€ 0.50

21

550D2015
ref: 21

PIN-COTTER,2.0X15

€ 1.00

22

550D2520
ref: 22

PIN-COTTER,2.5X20

€ 1.00

23

33001022
ref: 23
G3TR-A L=38.5 M/M (R

ARM-SWING

€ 130.50

24

33032030
ref: 24
G3TR-A

SWING ARM PIVOT SHAFT

€ 22.00

25

33040008
ref: 25
G3TR-A

ADJUSTER-CHAIN

€ 7.00

26

33040010
ref: 26
G3TR-A

ADJUSTER-CHAIN,LH

€ 8.00
