REAR WHEEL/CHAIN

ZX600E13 CANADA 2005

Rear wheel/chain diagram ZX600E13 CANADA 2005

REAR WHEEL/CHAIN ZX600E13 CANADA 2005
REAR WHEEL/CHAIN ZX600E13 CANADA 2005
REAR WHEEL/CHAIN ZX600E13 CANADA 2005
prices are in EUR
ref
part #
description
quantity
550
550D4035
ref: 550
PIN-COTTER,4.0X35
550D4035
€ 1.00
601
601B6204UU
ref: 601
BEARING-BALL,6204UUC3
601B6204UU
€ 28.00
601A
601B6205G
ref: 601A
BEARING BALL
601B6205G
€ 14.00
41068
410681350
ref: 41068
AXLE,RR
410681350
€ 139.00
41073
410731521GE
ref: 41073
WHEEL-ASSY,RR,G.GRAY
410731521GE
€ 780.00
42033
420331214
ref: 42033
COUPLING-ASSY,RR HUB
€ 283.00
42036
420361251
ref: 42036
SLEEVE,RR HUB,L=23
420361251
€ 18.00
42041
420411362
ref: 42041
SPROCKET-HUB
420411362
€ 47.00
42045
42045018
ref: 42045
NUT,18MM
42045018
€ 7.50
92004
920041275
ref: 92004
STUD
920041275
€ 6.50
92015
920151335
ref: 92015
NUT,FLANGED,10MM
920151335
€ 1.50
92027
920271902
ref: 92027
COLLAR,RR AXLE,L=21.5
920271902
€ 17.00
92033
920331042
ref: 92033
CIRCLIP,47M/M
920331042
€ 4.00
92033A
920331043
ref: 92033A
RING,SNAP,56.2M/M
920331043
€ 6.00
92049
920491056
ref: 92049
OIL SEAL,BJN28475
920491056
€ 8.50
92052
92052006
ref: 92052
OIL SEAL WTC35527
92052006
€ 6.50
92057
920570002
ref: 92057
CHAIN,DRIVE,EK50MV-XX
920570002
€ 215.00
92058
920581098
ref: 92058
JOINT-CHAIN,DRIVE
€ 8.50
92143
921431302
ref: 92143
COLLAR,RR AXLE,L=16
921431302
€ 28.50
92143A
921431303
ref: 92143A
COLLAR,RR HUB,L=133
921431303
€ 27.50
92160
921601399
ref: 92160
DAMPER,SHOCK,RR HUB
921601399
€ 57.00
92200
922001489
ref: 92200
WASHER
922001489
€ 1.50
