REAR HUB/CHAIN

ref

part #

description

quantity

1

42031034
ref: 1

AXLE,RR

€ 87.50

2

550D4035
ref: 2

PIN-COTTER,4.0X35

€ 1.00

3

42032077
ref: 3

REAR HUB COUPLING COLLAR

€ 26.50

4

42045005
ref: 4

NUT,10MM

€ 5.00

5

92088031
ref: 5

LOCK WASHER

€ 17.00

6

92001161
ref: 6

BOLT,10X41

€ 3.00

7

42041171
ref: 7

SPROCKET

€ 210.00

8

92057107
ref: 8
630X92L

CHAIN ASSY, DRIVE

€ 168.00

9

92050027
ref: 9

OIL SEAL

€ 13.50

10

920331044
ref: 10

CIRCLIP 62 M/M

€ 7.50

11

601B6206
ref: 11

BEARING-BALL,#6206C3

€ 19.50

12

42036032
ref: 12

COUPLING SLEEVE

€ 51.00

13

42008039
ref: 13
INCLUDES REF #S 3-6,

REAR HUB COUPLING ASSEMBLY

€ 718.00

14

42014031
ref: 14

SHOCK DAMPER

€ 161.00

15

92001183
ref: 15

BOLT

€ 10.00

16

92088030
ref: 16

LOCK WASHER

€ 8.00

17

601B6304
ref: 17

BEARING-BALL,#6304C3

€ 31.00

18

671B25115
ref: 18

O RING,115MM

€ 2.50

19

41088006
ref: 19

BEARING ADAPTER

€ 406.50

20

41039036
ref: 20

REAR HUB BEARING COLLAR

€ 39.50

21

41088005
ref: 21

BEARING ADAPTER

€ 146.00

22

920331043
ref: 22

RING,SNAP,56.2M/M

€ 6.00

23

92052008
ref: 23

OIL SEAL,TC26388

€ 45.00

24

92088032
ref: 24

LOCK WASHER

€ 9.50

25

42032061
ref: 25

COLLAR,REAR AXLE

€ 18.50

26

42036027
ref: 26

REAR CALIPER HOLDER SLEEVE

€ 37.50

27

92022248
ref: 27

WASHER,20.3X34X4.5

€ 7.50

28

42045018
ref: 28

NUT,18MM

€ 7.50
