IGNITION SWITCH/LOCKS/REFLECTORS
KZ1000A2A KZ1000 1978 CANADA
Ignition switch/locks/reflectors diagram KZ1000A2A KZ1000 1978 CANADA
IGNITION SWITCH/LOCKS/REFLECTORS KZ1000A2A KZ1000 1978 CANADA
×
prices are in EUR
ref
part #
description
quantity
1
270055008
ref: 1
SWITCH ASSY,IGNITION
€ 185.00
2
270165016
ref: 2
LOCK ASSY,STEERING
€ 97.00
3
92008007
ref: 3
SCREW-TAPPING
€ 2.50
4
92097003
ref: 4
WASHER
€ 2.50
5
110121134
ref: 5
CAP,STEERING LOCK
€ 4.50
6
27032001
ref: 6
SPRING-STEERING LOCK
€ 3.50
7
270165015
ref: 7
LOCK ASSY,SEAT
€ 88.50
8
112B0614
ref: 8
BOLT-UPSET 6X14
€ 2.50
9
461F0600
ref: 9
WASHER-SPRING,6MM
€ 0.50
10
410B0600
ref: 10
WASHER-PLAIN-SMALL,6M
€ 0.50
11
270165014
ref: 11
LOCK ASSY,HELMET
€ 59.00
12
110341134
ref: 12
BRACKET,HELMET LOCK
€ 3.50
13
112G0516
ref: 13
BOLT-UPSET
€ 0.50
14
461F0500
ref: 14
WASHER-SPRING,5MM
€ 0.50
15
27010017
ref: 15
SWITCH,BRAKE LAMP
€ 23.50
16
27011009
ref: 16
SPRING-BRAKE LAMP SW
€ 4.50
17
280121003
ref: 17
FRONT
REFLECTOR,REFLEX
€ 15.00
18
110341540
ref: 18
BRACKET,REFLEX REFLET
€ 6.50
19
112B0614
ref: 19
BOLT-UPSET 6X14
€ 2.50
20
461F0600
ref: 20
WASHER-SPRING,6MM
€ 0.50
21
411B0600
ref: 21
WASHER-PLAIN,6MM
€ 0.50
22
411B0500
ref: 22
WASHER-PLAIN,5MM
€ 0.50
23
461F0500
ref: 23
WASHER-SPRING,5MM
€ 0.50
24
311B0500
ref: 24
NUT-HEX
€ 0.50
25
280121054
ref: 25
REAR
REFLECTOR-REFLEX,RR
€ 15.00
26
270081103
ref: 26
KEY-LOCK,BLANK
€ 13.50
27
270045017
ref: 27
LOCK ASSY
€ 453.00
