SIDE COVERS/CHAIN COVER

KLX650C4 1996 USA CALIFORNIA CANADA

Side covers/chain cover diagram KLX650C4 1996 USA CALIFORNIA CANADA

SIDE COVERS/CHAIN COVER KLX650C4 1996 USA CALIFORNIA CANADA

SIDE COVERS/CHAIN COVER KLX650C4 1996 USA CALIFORNIA CANADA

prices are in EUR

ref

part #

description

quantity

36014

360141147
ref: 36014

CASE-CHAIN

€ 76.00

36030D

3603053296B
ref: 36030D

COVER-SIDE,LH,S.RED

€ 82.00

36030E

3603053306B
ref: 36030E

COVER-SIDE,RH,S.RED

€ 82.00

39156A

391561382
ref: 39156A

PAD,SIDE COVER,RH

€ 26.50

92143

921431196
ref: 92143

COLLAR

€ 3.00

92150

921501339
ref: 92150

BOLT,6X20

€ 2.50

92150A

921501340
ref: 92150A

BOLT,6X14

€ 3.00
