CABLES

EN500B2 1995 EUROPE UK FR NL AR FG GR IT NR SD SP ST

Cables diagram EN500B2 1995 EUROPE UK FR NL AR FG GR IT NR SD SP ST

CABLES EN500B2 1995 EUROPE UK FR NL AR FG GR IT NR SD SP ST
CABLES EN500B2 1995 EUROPE UK FR NL AR FG GR IT NR SD SP ST
CABLES EN500B2 1995 EUROPE UK FR NL AR FG GR IT NR SD SP ST
prices are in EUR
ref
part #
description
quantity
132
132E0610
ref: 132
BOLT-FLANGED-SMALL
132E0610
€ 2.50
220
220C0514
ref: 220
SCREW-PAN-CROS
220C0514
€ 1.00
482
482L5000
ref: 482
CIRCLIP-TYPE-E,5MM
482L5000
€ 1.00
550
550D2015
ref: 550
PIN-COTTER,2.0X15
550D2015
€ 1.00
43012
43012001
ref: 43012
SPRING,BRAKE ROD
43012001
€ 3.00
54001
540011200
ref: 54001
CABLE-SPEEDMETER
540011200
€ 23.50
54005
540051165
ref: 54005
CABLE-BRAKE
540051165
€ 46.50
54010
540101080
ref: 54010
CABLE,SEAT LOCK
540101080
€ 21.00
54011
540111336
ref: 54011
CABLE-CLUTCH
540111336
€ 20.50
54012
540121479
ref: 54012
CABLE-THROTTLE,CLOSIN
540121479
€ 26.00
54012A
540121480
ref: 54012A
CABLE-THROTTLE,OPENIN
540121480
€ 26.00
92015
92015042
ref: 92015
NUT-BRAKE ROD ADJUST
92015042
€ 4.00
92022
920221582
ref: 92022
WASHER,8.5X16X1.2
€ 0.50
92037
920371813
ref: 92037
CLAMP,CABLE
€ 5.50
92043
92043065
ref: 92043
PIN-BRAKE ROD
92043065
€ 3.50
92043A
920431013
ref: 92043A
PIN
920431013
€ 6.50
92075
920751980
ref: 92075
FG
DAMPER
920751980
€ 3.50
92170
921701023
ref: 92170
CLAMP
921701023
€ 12.50
92170A
921701498
ref: 92170A
CLAMP,BRAKE HOSE
921701498
€ 7.50
