FRONT FORK

ref

part #

description

quantity

224

224C0512
ref: 224

SCREW-PAN-WP-CROS,5X1

€ 2.00

11012

110121883
ref: 11012

CAP,FORK TOP

€ 17.50

44005

440051337
ref: 44005

PIPE-LEFT FORK OUTER

€ 271.50

44006

440061335
ref: 44006

PIPE-RIGHT FORK OUTER

€ 305.50

44013

440131397
ref: 44013

PIPE-FORK INNER

€ 125.50

44023

440231093
ref: 44023

CYLINDER-COMP-FORK

€ 87.00

44026

440261557
ref: 44026

SPRING-FRONT FORK

€ 29.50

44029

440291127
ref: 44029

SEAT-FORK SPRING

€ 33.00

44033

440331204
ref: 44033

COVER-FORK,LWR

€ 25.00

44033A

440331205
ref: 44033A

COVER-FORK,UPP

€ 18.50

44037

440371323
ref: 44037

HOLDER-FORK UNDER

€ 187.00

44039

440391250
ref: 44039

HOLDER-FORK UPPER

€ 112.50

44045

44045051
ref: 44045

GASKET,FORK CYLINDER (NAS)

€ 4.00

44065

440651109
ref: 44065

BUSHING-FRONT FORK

€ 15.50

44065A

440651110
ref: 44065A

BUSHING-FRONT FORK,IN

€ 16.00

44070

440705176
ref: 44070

DAMPER-ASSY,FORK

€ 1,111.50

92002

920021263
ref: 92002

BOLT-UPSET,6X40

€ 2.50

92015

920151193
ref: 92015

NUT,FLANGED,6MM

€ 0.50

92022

920221879
ref: 92022

WASHER

€ 3.00

92026

920261443
ref: 92026

SPACER,FORK

€ 5.50

92026A

920261444
ref: 92026A

SPACER,FORK,L=250

€ 14.50

92033

920331236
ref: 92033

RING-SNAP

€ 5.00

92033A

920331286
ref: 92033A

RING-SNAP

€ 5.50

92049

920491421
ref: 92049

SEAL-OIL,FORK OUTER

€ 13.50

92055

920551384
ref: 92055

RING-O,FORK SPRING SE

€ 3.00

92093

920931367
ref: 92093

SEAL,FORK OUTER

€ 14.00

92150

921501387
ref: 92150

BOLT,SOCKET,10X25

€ 3.50

92150A

921501407
ref: 92150A

BOLT

€ 2.00

92150B

921501432
ref: 92150B

BOLT

€ 6.50

92150C

921501511
ref: 92150C

BOLT,SOCKET

€ 2.00
