KICKSTARTER MECHANISM

ref

part #

description

quantity

1

312B0800
ref: 1

NUT,8MM

€ 0.50

2

463H0800
ref: 2

WASHER-TOOTHED,8MM

€ 2.00

2

463H0800
ref: 2

WASHER-TOOTHED,8MM

€ 2.00

3

13072004
ref: 3

KICKSTARTER STOPPER

€ 27.00

4

92042001
ref: 4

PIN-KICKSTARTER PAWL

€ 1.50

5

92081001
ref: 5

CLUTCH SPRING

€ 3.00

5

92081022
ref: 5

SPRING-KICK PAWL

€ 4.00

6

13067003
ref: 6

KICKSTARTER DRUM

€ 158.00

7

13069003
ref: 7

KICKSTARTER PAWL

€ 23.50

8

13068014
ref: 8

KICKSTARTER GEAR

€ 64.00

9

13071003
ref: 9

HOLDER,KICK SPRING

€ 1.50

10

482J0100
ref: 10

CIRCLIP-TYPE-E,10MM

€ 0.50

11

92082002
ref: 11

SPRING-KICKSTARTER

€ 16.50

12

13070001
ref: 12

GUIDE,KICK SPRING

€ 9.00

13

13063004
ref: 13

DAMPER,KICK PEDAL

€ 6.50

14

13066009
ref: 14

SHAFT-KICK

€ 29.50

14

13066014
ref: 14

SHAFT-KICKSTARTER

€ 21.50

15

13064016
ref: 15

PEDAL,KICKSTARTER

€ 165.50

15

13064016
ref: 15

PEDAL,KICKSTARTER

€ 165.50

16

13061002
ref: 16

BOSS

€ 50.00

16

13061007
ref: 16

BOSS-KICK PEDAL

€ 50.00

17

92081020
ref: 17

SPRING-KICK PEDAL

€ 2.50

18

600A0800
ref: 18

BALL-STEEL,1/4

€ 0.50

19

92001071
ref: 19

BOLT,10MM

€ 10.50

19

92001071
ref: 19

BOLT,10MM

€ 10.50

all assemblies
