CRANKSHAFT/PISTON(S)

ref

part #

description

quantity

12046

120460033
ref: 12046

SPROCKET,16T

€ 38.50

13001

130010044
ref: 13001

PISTON-ENGINE

€ 110.00

13002

130020004
ref: 13002

PIN-PISTON

€ 24.00

13008

130080005
ref: 13008

RING-SET-PISTON

€ 58.00

13031

130310033
ref: 13031

CRANKSHAFT-COMP,"A" M

€ 1,559.00

13031A

130310034
ref: 13031A

CRANKSHAFT-COMP,NO MA

€ 1,559.00

13031B

130310035
ref: 13031B

CRANKSHAFT-COMP,"B" M

€ 1,485.00

13251

132510005JJ
ref: 13251

ROD-ASSY-CONNECTING,J

€ 212.00

13251A

132510005KK
ref: 13251A

ROD-ASSY-CONNECTING,K

€ 212.00

92015

920151311
ref: 92015

NUT,FLANGED,8MM

€ 4.50

92033

920331054
ref: 92033

CIRCLIP,PISTON PIN

€ 2.00

92139

921390026
ref: 92139

BUSHING,CRANK PIN,BLU

€ 16.00

92139A

921390027
ref: 92139A

BUSHING,CRANK PIN,BLA

€ 16.00

92139B

921390028
ref: 92139B

BUSHING,CRANK PIN,BRO

€ 16.00

92139C

921390029
ref: 92139C

BUSHING,CRANK #1&#5,B

€ 16.00

92139D

921390030
ref: 92139D

BUSHING,CRANK #1&#5,B

€ 16.00

92139E

921390031
ref: 92139E

BUSHING,CRANK #1&#5,B

€ 16.00

92139F

921390032
ref: 92139F

BUSHING,CRANK #2&#3&#

€ 14.50

92139G

921390033
ref: 92139G

BUSHING,CRANK #2&#3&#

€ 14.50

92139H

921390034
ref: 92139H

BUSHING,CRANK #2&#3&#

€ 14.50

92153

921530809
ref: 92153

BOLT,8X45.5

€ 3.00
