REAR HUB

KX500-E8 1996 EUROPE AS

Rear hub diagram KX500-E8 1996 EUROPE AS

REAR HUB KX500-E8 1996 EUROPE AS
REAR HUB KX500-E8 1996 EUROPE AS
REAR HUB KX500-E8 1996 EUROPE AS
prices are in EUR
ref
part #
description
quantity
410
410B0800
ref: 410
WASHER-PLAIN-SMALL,8M
410B0800
€ 0.50
550
550D3025
ref: 550
PIN-COTTER,3.0X25
550D3025
€ 0.50
11012
110121581
ref: 11012
CAP,AXLE
110121581
€ 4.00
41034
410341205
ref: 41034
DRUM-ASSY,REAR BRAKE
410341205
€ 440.50
41068
410681299
ref: 41068
AXLE,RR
410681299
€ 59.50
42041
420411154
ref: 42041
SPROCKET-HUB,45T
€ 84.00
42041A
420411256
ref: 42041A
SPROCKET-HUB,49T,AL
420411256
€ 75.00
42041B
420411257
ref: 42041B
SPROCKET-HUB,48T,AL
420411257
€ 87.50
42041C
420411258
ref: 42041C
SPROCKET-HUB,47T,AL
420411258
€ 75.00
42041D
420411259
ref: 42041D
SPROCKET-HUB,46T,AL
€ 105.00
42041E
420411382
ref: 42041E
SPROCKET-HUB,47T
420411382
€ 38.50
92015
920151432
ref: 92015
NUT,8MM
920151432
€ 4.50
92015A
920151804
ref: 92015A
NUT,CASTLE,20MM
920151804
€ 7.50
92022
920221994
ref: 92022
WASHER,20.1X34X2.0
920221994
€ 3.00
92033
920331041
ref: 92033
CIRCLIP,42MM
920331041
€ 4.00
92045
920451239
ref: 92045
BEARING-BALL,6004X8JR
920451239
€ 30.00
92049
920491203
ref: 92049
SEAL-OIL,BJNC2 25425
920491203
€ 12.00
92057
920571317
ref: 92057
CHAIN,DRIVE,DID520DSX
€ 103.50
92058
920581068
ref: 92058
JOINT-CHAIN,DRIVE
€ 6.50
92143
921431356
ref: 92143
COLLAR,RR AXLE,L=20
921431356
€ 25.50
92143A
921431402
ref: 92143A
COLLAR,RR BRAKE DRUM,
921431402
€ 10.50
92150A
921501978
ref: 92150A
BOLT
921501978
€ 5.50
