CHASSIS ELECTRICAL EQUIPMENT

AR125A7 1989 UNITED KINGDOM GR NR

Chassis electrical equipment diagram AR125A7 1989 UNITED KINGDOM GR NR

CHASSIS ELECTRICAL EQUIPMENT AR125A7 1989 UNITED KINGDOM GR NR
CHASSIS ELECTRICAL EQUIPMENT AR125A7 1989 UNITED KINGDOM GR NR
CHASSIS ELECTRICAL EQUIPMENT AR125A7 1989 UNITED KINGDOM GR NR
prices are in EUR
ref
part #
description
quantity
130
130B0610
ref: 130
BOLT,FLANGED,6X10
130B0610
€ 0.50
130A
130B0614
ref: 130A
BOLT-FLANGED
130B0614
€ 0.50
14024
140241329
ref: 14024
COVER,HARNESS
€ 8.00
21061
210611003
ref: 21061
RECTIFIER
210611003
€ 25.00
26001
260011795
ref: 26001
HARNESS,MAIN
260011795
€ 145.50
26004
260041013
ref: 26004
FUSE-ASSY
€ 20.00
26006
260061003
ref: 26006
FUSE,15A,L=30M/M
260061003
€ 3.00
26011
260111193
ref: 26011
WIRE-LEAD,BATTERY,(+)
260111193
€ 7.50
26011A
260111194
ref: 26011A
WIRE-LEAD,BATTERY,(-)
260111194
€ 7.00
26012
260121157
ref: 26012
BATTERY,12V 5AH,12N5
€ 63.00
27002
270021053
ref: 27002
RELAY-ASSY,TURN SIGNA
270021053
€ 33.50
27003
270031249
ref: 27003
HORN
€ 37.50
92002
920021721
ref: 92002
BOLT,6X12
€ 2.00
92037
92037113
ref: 92037
CLAMP
92037113
€ 4.00
92072
92072031
ref: 92072
BAND,MIDDLE
92072031
€ 3.00
